Skärande- och hållande verktyg

Track design: Right, normal spiral, wide tracks.
Tip angle: 118° Special tip geometry (DORMER P.S. Point), provides better positioning accuracy.
Surface treatment: Blank body, TiN-coated cutting part.
Area of ??use: For normal drilling work.
DIN 338 RN / BS 328 / ISO 235.
* = Self-service packed.

(HTML text not available)

Drill sets A095 with drills type A002.
Groove design: Right, normal spiral, wide grooves.
Point angle: 118° special tip geometry (Dormer P.S. Point), gives better positional accuracy.
Surface treatment: Glossy body, TiN-coated cutting part.
Area of ??use: For normal drilling work.
DIN 338 RN / BS 328 / ISO 235

4-edged hammer drill with SDS-Plus attachment. Solid HM tip with precise centering on hard and smooth surfaces. Four symmetrical 90° cutting edges guarantee round holes and reduce the risk of jamming when drilling in rebar. Large inlet channels ensure optimal removal of the drilling dust. Four symmetrical input channels provide low vibrations and ensure low and even track wear. Suitable for brick, concrete, reinforced concrete and natural stone.
Diameter Ø 18 mm > carbide tip.
Drill with working length 400-940 mm: Pre-drill with a shorter drill of the same diameter.

Tolerances: 6H.
Cutting phase: Form B (Intermediate pin, 3.5-5 threads chamfered).
Slot design: Chip driving cutting.
Surface treatment: Steam treated.
Area of ??use: For threading through holes.
ISO 529.

Center drill for Pro-Fit hole saws.

Track design: Right, normal spiral.
Tip angle: 118° < 2.3 mm and > 13 mm 135° 2.3 mm - 13 mm. Cross-pointed.
Surface treatment: Glossy: < 1 mm. Steam run > = 1 mm.
Area of ??use: For normal drilling work in steel, stainless steel and cast iron. Also suitable for use in handheld machines.
DIN 1897 RN / BS 328 / ISO 235

Tolerances: 6H.
Cutting chamfer: Form C (Step taper, 2-3 threads chamfered).
Groove design: Chip-pulling right-hand spiral 45 °.
Surface treatment: Steam run.
Application area: For threading bottom holes.
ISO 529.

Borren är lämplig för stationära maskiner och handhållna maskiner. Borrspetsen är av typen split-point, slipad vid 135°, vilket säkerställer bra bearbetning från start och är särskilt effektiv i hårda material. Tillverkad i enlighet med DIN 338 för toleranser med hög precision och geometrisk noggrannhet DIN 338 Cobolt 5% M35 stål Ljus finish Borrspetsen, split-point slipad vid 135° Spiralerna slipas och vinklas i 30° för att säkerställa effektiv borttagning av spån Rekommenderas för: Stål, rostfritt stål, aluminium, gjutjärn, mässing, koppar, gips, trä och plast Setet innehåller följande borrar: 1 - 1,5 - 2 - 2,5 - 3 - 3,5 - 4 - 4,5 - 5 - 5,5 - 6 - 6,5 - 7 - 7,5 - 8 - 8,5 - 9 - 9,5 - 10 - 10,5 - 11 - 11,5 - 12 - 12,5 - 13 mm

Groove design: 25° left spiral.
Shaft: Morse taper MK.
Conicity: 1:10.
Surface treatment: Glossy.
Material: HSS.
Tolerance: K11.
Area of ??use: For centering overlapping holes at e.g. rivet and screw connections in most materials.
DIN 311.

Magnetic search system that facilitates drilling for electrical boxes in both hard and soft sheet materials, e.g. chipboards, OSB boards, gypsum boards, wooden panels, plywood, etc. The system is adapted to all electrical boxes on the Swedish and Norwegian market. Hole finder with powerful magnet.

Cutting version: Right. Straight inserts.
Conicity: 1:48.
Area of ??use: For hand reaming holes for conical pins (1:48), in most materials.< BR>BS 328.

Konicitet: 1:50
Ytbehandling: Ånganlöpta spår, blanka styrkanter
Användningsområde: För brotschning av hål med kona 1:50
*_Skaftdiameter: Enligt BS 328
DIN 9 A / BS 328 / ISO 3465

Cutting version: 7° left. Straight cuts for diam. 1 - 2.5 mm.
Conicity: 1:50.
Area of ??use: For reaming holes for conical pins (1:50), according to DIN 258, DIN 7977 and DIN 7978, in most materials.
DIN 9 B.

Groove design: 45° left spiral.
Shaft: Cylindrical with tongue.
Conicity: 1:50.  ;
Surface treatment: Glossy.
Material: HSS-E.
Area of ??use: For reaming holes for conical pins (1:50) acc. DIN 258, DIN 7977 and DIN 7978 in most materials.
DIN 2179.

Groove design: 45° left spiral.
Shaft: Morse taper MK.
Conicity: 1:50.
Surface treatment: Glossy.
Material: HSS-E.
Application: For reaming holes for conical sticks (1:50) acc. DIN 258, DIN 7977 and DIN 7978 in most materials.
DIN 2180.

Transition between external machine attachment 1 1/4" to Fröken drill attachment. Fits Dima's diamond core drill with Fröken drill attachment.

Transition between external machine mount 1 1/4" to Pixie drill mount. Fits Dima's diamond core drill with Pixie drill mount.

Transition between external machine mount 1 1/4" to Pixie drill mount. Used in conjunction with anti-friction element placed between the adapter and the drill, acts as a spring-loaded washer and facilitates removal of the drill from the adapter. Fits Dima's diamond core drill with Pixie drill mount.

Adapter for using diamond core drill with Fröken drill attachment together with drill machine equipped with quick chuck or key chuck. 3-Edge attachment for secure grip in the chuck. Fits Dima's diamond core drill with Fröken drill attachment.

Adapter for using diamond core drills with Pixie drill attachment together with drilling machine equipped with quick chuck or key chuck. 3-Edge attachment for secure grip in the chuck. Fits Dima's diamond core drill with Pixie drill attachment.

Transition between machine attachment Fröken to Pixie drill attachment. Fits Dima's diamond core drill with Pixie drill attachment.

Parting blade for holder DU and D. Suitable parting blade: LFMX.

Fits band saw BOSCH GCB 18 V.

M42 band saw blades with teeth hardened to 69 Rockwell and made from HSS steel with 8% cobalt. Highly elastic back in spring steel alloy with 4% chrome (from height 27 mm). Combined tooth assembly with constant side width. Depending on the number of teeth and development, the sawing characteristic lies in tooth patterns with a positive rake angle of 10° (hook-shaped tooth). Suitable for standard sawing with metal saws. Recommended for plain steel and stainless steel, structural steel, carbon steel, casting and light alloys.

Bi-metal band saw blade. High speed steel teeth with 8% cobalt for fast cutting speed and long service life. Extremely hard and smooth teeth plasma welded to a strong and durable back. High-speed sawing of aluminum, angle iron, bronze, brass, copper, galvanized pipes and soft iron. Harder steels including stainless, chrome, tungsten plus other difficult materials are cut at low speed.

Bi-metal band saw blade. High speed steel teeth with 8% cobalt. Extra long service life. Precision-shaped teeth that provide fast, clean cuts. Optimized for battery-powered band saws. Suitable for cutting angle iron, galvanized pipes and even harder steels such as cast iron and stainless steel.

Concrete drill with cylindrical attachment. Suitable for concrete, masonry, limestone, natural stone and artificial stone. Durable drill as for all impact drills.

Borsett med betongbor beregnet for bormaskiner, skrutrekkere og bor-/skrutrekkere. Egnet for betong, murverk, kalkstein, naturstein og kunststein. Sylindrisk feste.

Holder for cutting blade XLCFN.

Track design: Right, normal spiral.
Point angle: 135° cross point. 118° tip up to 2.9 mm.
Surface treatment: TiN (Titanium nitride). Blank under 2.0 mm.
Area of ??use: For normal drilling work.
DIN 1897.

Groove design: Right, normal spiral.
Tip angle: 118°.
Surface treatment Glossy: < 1 mm, 3/64, No 60.
Surface treatment Steam run: 1 mm, 3/64, No 60 and larger.
Area of ??use: For normal drilling work.
DIN 338 RN / BS 328 / ISO 235.

Groove design: Left, normal spiral.
Tip angle: 118°, left cutting.
Surface treatment: Glossy under 3 mm. Steam hardened 3 mm and larger.
Area of ??use: For normal drilling work in steel, cast iron etc. in left-hand machines.
DIN 338 LN / BS328 / ISO 235.

Track design: Right, large spiral angle.
Tip angle: 135° < 1.5mm 135° > = 1.5 mm. Cross-tipped.
Surface treatment: Steam treated.
Application: For drilling in austenitic stainless acid and heat-resistant steels.
DIN 338 RW / BS 328 / ISO 235.

Groove design: Right, normal spiral.
Tip angle: 118°, 14 mm and larger, pointed.
Surface treatment: Glossy: < ; 1 mm. Steam Run: > = 1 mm.
Area of ??use: For drilling deep holes in steel, cast iron, etc.
DIN 340 RN / BS 328 / ISO 494

Track design: Right, normal spiral.
Tip angle: 118° up to 1.5 mm, 135° 1.5 mm and larger. Cross-pointed.
Surface treatment: Yellow-coated.
Area of ??use: For drilling in CNC and automatic machines. For high-strength and high-alloy steels 1200 N/mm².
DIN 1897 RN / BS 328 / ISO 235

Groove design: Right, normal spiral, thin conical core, no guide edges.
Point angle: 120°.
Surface treatment: Steamed.< BR>Area of ??use: For drilling in thin sheet metal and thin material sections up to 1.25 x D. The self-centering tip produces accurately round holes.
Used as pop rivet drill.
Total length according to DIN 1897 RN / BS328 / ISO 235

Track version: Right, normal spiral.
Tip angle: 120°.
Surface treatment: Glossy/steamed.
Area of ??use: For normal drilling work in steel, copper, brass, bronze and aluminium. Also suitable for use in handheld machines.
DIN 1897

Groove design: Right, small spiral angle.
Tip angle: 118°.
Surface treatment: Black grooves, shiny guide edges, tip and shaft .
Carbide quality: HM K20.
Application: For drilling in very hard and abrasive materials.
DIN 8037 RH, (with heavy DIN1809)

Track design: Right, normal spiral.
Tip angle: 118°.
Surface treatment: Glossy: < 2.2 mm. Steam run: > = 2.5 mm.
Area of ??use: For normal drilling work in steel, cast iron etc.
ISO 3292 / BS 328
